Advance Marine Reduction Gearbox MA100A Series for Boat And Ship Main Propulsion

Advance marine reductiong gearbox MA100A series, center distance 100mm, rated thrust 3KN, ratio 1.6-3.88:1, 75kg, 236*390*420mm, max engine power 37hp 3000rpm, typical engine Isuzu UM02AB1, Yamaha ME125, flywheel SAE 7.5inch, 10inch, 11.5inch.

Model:
MA100A
Brand:
Advance
Code:
HMMA100A

Availability:

Quantity:



Inquire Add to Basket

Product Description

Advance Marine Reduction Gearbox MA100A Series for Boat And Ship Main Propulsion, with detailed specifications in below:

Application	Marine
Model	MA100A
RPM input	1500-3000
Center distance	100mm
Rated propulsion	3 kN
Reduction ratio	1.60	2.0	2.55	3.11	3.59	3.88
Transmitting capacity	0.009		0.007		0.006
Overall dimensions	236mm * 390mm * 420mm
Net dry weight	75kg
Flywheel (flange)	SAE 11.5 inch, 10 inch, 7.5 inch
Flywheel (bell) housing	SAE 3#, 4#, 5#
Control	mechanical remote operation
Maximum engine power	37hp 3000rpm
Typical compatible engines	Isuzu UM02AB1, Yamaha ME125
