Advance Marine Reduction Gearbox HCT600A-1 Series for Boat And Ship Main Propulsion

Advance marine reduction gearbox HCT600A-1 series, ratio 7.69 - 14.44:1, center distance 500mm, rated propulsion 140KN, 1700kg, 878*1224*1346mm, max engine power 1260hp 2100rpm, SAE 14 inch, 16 inch, 18 inch, 21 inch, flywheel housing SAE 0#, 00#, typical engine KTA38-M940, TBD234V16.

Model:
HCT600A-1
Brand:
Advance
Code:
HMHCT600A-1

Availability:

Quantity:



Inquire Add to Basket

Product Description

Advance Marine Reduction Gearbox HCT600A-1 Series for Boat And Ship Main Propulsion, with detailed specifications, in below:

Model	HCT600A-1
RPM input	1000 - 2100rpm
Center distance	500mm
Rated propulsion	140KN
Reduction ratio	7.69	8.23	8.82	9.47	10.1	10.8	11.65	12.57	14.44
Transmitting capacity	0.441		0.412	0.40	0.375		0.353	0.331	0.257
Overall dimensions	878mm * 1224mm * 1346mm
Net dry weight	1700kg
Flywheel (flange)	SAE 21 inch, 18 inch, 16 inch, 14inch
Flywheel (bell) housing	SAE 00#, 0#
Control	mechanical remote operation
Maximum engine power	1260hp 2100rpm
Typical compatible engines	Cummins KTA38-M940, Deutz MWM TBD234 V16
