Advance Marine Reduction Gearbox HCD800 Series for Boat And Ship Main Propulsion

Advance marine gearbox HCD800 series, ratio 3.429 - 5.889 :1, 1900kg, 1056 * 1280 * 1341mm, center distance 450mm, rated thrust 110KN, input speed 1000-1800RPM, flywheel SAE 16/18/21 inch, flywheel housing SAE 0# or 00#, max engine power 1530hp 1800rpm, manual or electric or pneumatic control, typical engine KTA38-M1, CW6200, 6190Z1CZ, etc.

Model:
HCD800
Brand:
Advance
Code:
HMHCD800

Availability:

Quantity:



Inquire Add to Basket

Product Description

Advance Marine Reduction Gearbox HCD800 Series for Boat And Ship Main Propulsion, with detailed specifications, in below:

Model	HCD800
RPM input	1000 - 1800rpm
Center distance	450mm
Rated propulsion	110KN
Reduction ratio	3.429	3.96	4.391	4.905	5.474	5.889
Transmitting capacity (kw/rpm)	0.625			0.588	0.551	0.515
Overall dimensions	1056mm * 1280mm * 1341mm
Net dry weight	1900kg
Flywheel (flange)	SAE 21 inch, 18 inch, 16 inch
Flywheel (bell) housing	SAE 00#, 0#
Control	Manual hydraulic, electrically, pneumatically
Maximum engine power	1530hp 1800rpm
Typical compatible engines	6190Z1CZ, CW6200, Cummins KTA38-M1
