Weichai Baudouin Marine Generator Set 425-545kva with Engine 6M26.2 Series

Weichai Bauduoin marine genset, with engine 6M26.2 series, 50 - 60 Hz, 425kva - 545kva, 3300kg.
  • 6M26.2

  • Weichai Baudouin

  • HM340WGM

Availability:
Quantity:

Weichai Baudouin Marine Generator Set 425-545kva with Engine 6M26.2 Series, with detailed genset specifications, in below:

Engine Model

6M26.2

Number of Cylinders

6 cylinders, in line

Cycle

4 stroke

Aspiration

Turbocharged, water-air aftercooled

Bore * Stroke

150 * 150mm

Displacement

15.9 L

Genset Rating

Hz

Prime Power

Fuel Consumption


KVA

KW

L/H

50

425

340

86

50

455

364

91

50

520

416

104

60

475

380

98

60

545

436

112

Overall Dimension (mm)

3070 * 1370 * 1450

Weight (kg)

3300

6M26 800X800 watermark -16M26 800X800 watermark -26M26 800X800 watermark -3

Engine origins from Weichai, biggest engine manufacturer in China.

As for us, we focus in Cummins, who produces most Cummins engine series in China, including:



SN

Models

1

4BT3.9, 6BT5.9, 4ISBE4.5, 6ISBE6.7, QSB4.5, QSB6.7, ISB

2

6CT8.3, L8.9, L9.3, L9.5, ISLe8.9, QSL

3

MTA11, QSM, ISME

4

ISF2.8, ISF3.8, QSF2.8, QSF3.8

5

ISZ13, QSZ13, ISG

6

NT855

7

KT19, KT38, KT50, QSK19, QSK38, etc



for different applications, such as:



SN

Applications

1

diesel generator set

2

water pump set, fire pump set

3

construction and engineering machinery (crane, excavator, bulldozer, loader, etc)

4

Automobile (bus, coach, shuttle, etc)

5

marine main propulsion, marine auxiliary generator set



And besides complete engines, we also export a lot of engine parts parts, including:



SN

Part Descriptions

1

cylinder head, cylinder block, cylinder liner

2

piston, piston ring, conrod

3

main bearing, conrod bearing, thrust bearing

4

fuel injector, fuel injection pump, common rail

5

oil pan gasket, cylinder head gasket

6

overhaul gasket kit, upper gasket kit, lower gasket kit

7

oil pan

8

fuel transfer pump, water pump, oil pump, vacuum pump, power steering pump

9

oil filter, fuel filter, fuel water separator, air filter, Etc



Beyond Cummins, we also deal with many other brands of engines and gearboxes, etc, including:



SN

Brands

1

Deutz, MWM

2

CAT

3

Detroit

4

Weichai

5

Yuchai

6

SDEC

7

Advance

8

Fada

9

Jinbei, Brilliance

10

Yuejin

11

WEICHAI



FAQ:

Question: What is the price ?

Answer: Our prices are determined by various factors, including: Brand, Model, Power, Quantity, Price Term (FOB, CIF, CPT, FCA, etc), Certificates, etc.

Question: What is the MOQ ?

Answer: for complete engine, 1 set; for engine parts, 1 engine set;

Question: Are samples available ?

Answer: Sample order is acceptable, but with higher unit price.

       For regular partners, if necessary, free samples are available.

Question: How long is the production cycle (lead time) ?

Answer: for engine parts, we usually have enough stock; for engines, usually around 10-20 days; for stock engine, usually 1 week.

Question: How long is the shipment?

Answer: if by Express, usually 3-4 working days; if by air, usually 3-5 working days; if by sea, 3-7 days to Southeast Asia, 15-20 days to Middle East, South Asia and Australia, 20-25 days to Europe, USA and Africa, 30-35 days to Latin America and other regions.

Question: What are your payment methods ?

Answer: we accept T/T (bank wire transfer), L/C, Western Union, Money Gram, Sigue, Secured Trade through Made-in-China, etc.

Question: Do you supply any other brand ?

Answer: we entered stock engine industry since 2016, mainly focusing in engines in stock, never used, still under good condition, made in US/UK/Germany/Japan/Korea/China, etc. Sometimes we have stocks of other brands than our normal list of brands. Thus, any inquiry is warmly welcomed and we will always do best to support customers.
