Weichai 8170ZX Series Marine Diesel Engine for Boat And Ship Main Propulsion 441kw - 601kw

Weichai medium speed marine engine 8170 series, for boat and ship main propulsion, from 441kw 1000rpm to 601kw 1350rpm, 8 cylinders in line, 170mmx200mm, 36.3L, 2577x1117x1844mm, 3800kg.
  • 8170ZC

  • Weichai

  • HM8170ZC

Availability:
Quantity:

Weichai 8170ZX Series Marine Diesel Engine for Boat And Ship Main Propulsion 441kw - 601kw, with main list of Weichai marine engines, in below:

Model

Liter

KW/HP/RPM

KW/HP/RPM

KW/HP/RPM

KW/HP/RPM

KW/HP/RPM

Weichai

WP2.1

2.1

20/27/2000

26/35/2700




WP3.9

3.9

38/53/2000

45/61/2400




226B-3C

3.1

35/48/1800

40/54/1500

50/68/1800



WP4

4.5

60/82/1500

70/95/1800

75/102/2100

88/120/1800


WP6

6.8

90/122/1500

103/140/2300

105/142/1800

110/150/1500

115/156/2100

WP6

6.8

120/163/2300

122/165/1800

136/185/2100

145/198/2300

162/220/2300

WP6

6.8

168/228/2425





WD10

9.7

140/190/1500

140/190/1800

147/200/1800

147/200/2100

160/218/1500

WD10

9.7

176/240/1500

176/240/100

190/258/1500

205/278/1500

205/278/1800

WD10

9.7

205/278/2100

220/300/2100

230/312/1800

240/326/2100


WD12

11.6

220/300/1500

220/300/1800

240/327/1500

240/327/1800

258/350/1800

WD12

11.6

275/375/2150

294/400/2150




WP12

11.6

258/350/1500

295/400/1800

330/450/2100

368/500/2100

405/550/2100

WP13

12.5

330/450/1800

368/500/1800




R6160

27.1

164/223/1000

184/250/1000

202/275/1000

220/300/1000

255/350/1000

R6160

27.1

280/380/1000

300/408/1000

330/450/1000

360/490/1200


X6170

27.2

300/408/1000

330/450/1000

330/450/1200

353/480/1200

368/500/1200

X6170

27.2

382/520/1200

397/540/1200

426/580/1350



8170ZC

36.3

441/600/1000

530/720/1200

601/818/1350



CW6200

50.9

450/612/750

540/734/900

540/734/750

600/816/1000

600/816/750

CW6200

50.9

648/881/900

698/949/1000

720/979/1000

810/1102/1000

828/1126/1000

WH20

56.55

720/980/600

825/1122/750

864/1175/720

900/1225/750

905/1230/900

WH20

56.55

905/1230/1000

1000/1360/830

1000/1360/900

1000/1360/1000

1066/1450/1000

WH20

56.55

1080/1470/900

1118/1520/1000

1200/1632/1000

1320/1795/1000


CW8200

67.9

720/979/900

800/1088/1000

864/1175/900

928/1262/1000

960/1306/1000

CW8200

67.9

1030/1401/1000





CW12V200

101.8

1080/1469/900

1200/1632/1000

1296/1763/900

1392/1893/1000

1440/1958/1000

CW16V200

135.7

1440/1958/900

1600/2176/1000

1760/2394/1000



WH28

151.5

1838/2500/650

2050/2790/650

2100/2856/650

2160/2940/720

2206/3000/750

WH28

151.5

2250/3060/750

2400/3265/750

2400/3265/800

2700/3675/800


CW6250

88.4

1060/1442/720

1103/1500/750

1323/1799/900

1470/1999/1000


CW8250

117.8

1470/1999/750

1760/2394/900

1960/2666/1000



Baudouin

4W105M

4.5

95/130/2100





6W105M

6.75

136/185/2100

168/228/2425

185/252/2500



6M16

9.7

264/360/2100





6M19.3

11.6

294/400/1800

331/450/1800

368/500/2100

404/550/2100

425/578/2200

6M26

15.9

331/450/1800

368/500/1800

404/550/1900

442/600/1950

485/660/1800

6M26

15.9

515/700/2000

551/750/2100

599/815/2100



8M26

21.2

442/600/1800

491/668/1800

539/733/1900

588/800/1950


12M26

31.8

662/900/1800

736/1000/1800

808/1100/1900

883/1200/1950


6M33

19.6

478/650/1800

515/700/1800

551/750/1800



12M33

39.2

956/1300/1800

1029/1400/1800

1103/1500/1800
